HJ215 WaterJet
The HJ215 stands as the latest waterjet of the new generation, boasting a redesigned structure that ensures high-speed efficiency, increased bollard pull through the incorporation of the TURBO2 impeller range, and customizable Trim Nozzle options. This model redefines performance, with heightened durability and simplified installation.
HJ215 SpecificationsDOWNLOAD PDF
HJ214 - HJ215 BrochureDOWNLOAD PDF
Description
Key Features of the HJ215:
- Maximum Input Power: 260 kW / 349 hp
- Maximum RPM: 4800 rpm
- Maximum Speed: 50 Knots
- Jet Type: Axial Flow
- Dry Weight of Jet: 87 kg / 192 lbs (with Trim Nozzle)
- Entrained Water: 21 kg / 46 lbs
- Weight of Intake Block: 7 kg / 15 lbs
- Jet Construction: Marine Grade Aluminium / Duplex SS
- Shaft Angle: 5°
- Rotation: Left-Hand
- NEW OPTION – Factory-manufactured TURBO2 Impeller range
- NEW OPTION – Trim Nozzle ±10°
- Electrically actuated Trim Nozzle option
- Improved Acceleration with the new TURBO2 impeller
- Inboard footprint remains the same as the previous model
- Enhanced reverse duct design
- Improved minimum speed
- Control Compatibility: HSRX, AVXexpress
- Advanced Corrosion Protection
